JOST LANDING LEG SET - ROCKER FOOT - 14 INCH BODY - 17 INCH TRAVEL

DESIGN FEATURES

• INTERNAL GEARBOX PROTECTS GEARS AND PREVENTS SHAFT MISALIGNMENT.
• COVER AND BUSHINGS SEALED TO KEEP MOISTURE OUT.
• DOUBLE “D” STYLE SHAFT ALLOWS CRANK FORCE TO GO DIRECTLY INTO THE GEARBOX, NOT TORQUING THE BOLT.
• 10 BOLT MOUNTING PATTERN ADDS MOUNTING RIGIDITY.
• REINFORCING STRAP AT THE BOTTOM OF THE UPPER HOUSING FOR ADDED STRENGTH.
• AUSTEMPERED DUCTILE IRON GEARS WILL NOT WEAR OUT.
• SHORT BODY FOR EXTRA HIGH GROUND CLEARANCE


TECHNICAL DATA

LIFT CAPACITY :  25000 kg

STATIC LOAD :  80000 kg

SIDE LOAD CAPACITY :  14500 kg

STROKE :  431mm

EXTENDED :  1235mm

RETRACTED :  803mm

LIFT PER TURN LOW GEAR :  0.09mm

LIFT PER TURN HIGH GEAR :  15.0mm
