Chris's Body Builders

JOST LANDING LEG SET - FLAT FOOT - 14 INCH BODY - 17 INCH TRAVEL

Regular price $850.00 AUD
Regular price Sale price $850.00 AUD
Sale Sold out
DESCRIPTION:



DESIGN FEATURES

  • Internal gearbox protects gears and prevents shaft misalignment.
  • Cover and bushings sealed to keep moisture out.
  • Double “D” style shaft allows crank force to go directly into the gearbox, not torquing the bolt.
  • 10 bolt mounting pattern adds mounting rigidity.
  • Reinforcing strap at the bottom of the upper housing for added strength.
  • Austempered ductile iron gears will not wear out.
  • Short body for extra high ground clearance

TECHNICAL DATA

LIFT CAPACITY :  25000 kg

STATIC LOAD :  80000 kg

SIDE LOAD CAPACITY :  14500 kg

STROKE :  431mm

EXTENDED :  1158mm

RETRACTED :  727mm

LIFT PER TURN LOW GEAR :  0.09mm

LIFT PER TURN HIGH GEAR :  15.0mm
